Packing press 50P1 with shift press cage

150 kg/h. Packing press with sliding juice basin.

For more information regarding this particular product
please use the Product Enquiry Tab Below.
For any other Enquires please use our Contact Us Form.

Product Description

Packing press with moveable juice basin (sliding carriage) and hydraulic power unit. Easy and safe operation thanks to automatic pressure relief valve on hydraulic power unit.

TECHNICAL DATA

Nominal rating kg/h 150 kg/h
Motor rating 1,1 (1,5) kW (PS)
Connected load Various Voltages Available
Electrical protection T.B.D.
Length 1100 mm
Width 990 mm
Height 1430 mm
Discharge height 1080 mm
Weight 160 kg
Material Packer frame and juice basin in 1.4301 / AISI 304
Press force 14 to
Press pressure 380 bar
Juice yield 75 %
Connection for juice outlet Ø30mm
Height juice outlet 470 mm
Scope of supply 7 press cloths 70×70 cm, 8 press inserts in acacia wood 41×41 cm
